Frameless: Clutter Free And Classy
Frameless enclosures add to the aesthetic appeal of the bathroom as more glass and less hardware gives a spacious look to the bathroom. These maintain the functionality and effectiveness with the usage of minimum fittings and fixtures. Available in both 8mm and 10 mm thick glass with standard and customised options.
Jaquar’s Ready-to-Fit Shower Enclosures are a must for every bathroom to minimise the dangers of slipping and falling.
• Readily available in standard sizes
• Separates dry and wet areas and optimises bath spaces
• Easy Clean (Anti Limescale Treatment)
• Brass Hardware
• Made of toughened safety glass and high-quality hinges
• Choose from Frameless, Semi-framed and Framed enclosures
• One-stop solution (Design – Installation – Maintenance)
• Available at leading sanitaryware stores
• 5 Years Warranty on Hardware
features
Tempering for shower enclosure glasses only
90% of an enclosure is glass, so glass must conform to the highest safety standards as it is used in the bathroom
Quality checks :
Fragmentation test : to check breakage pattern of glass
- Zebra test: no waviness
- Ball drop test (impact resistance): to check strength at point of impact
- Visual defects: to check bubbles, scratches, chipping at edges and other visible defects
- Free fall test: to check overall strength of glass, by throwing the glass freely on a plain surface
Standards :
- These standards ensure that the glass passes stringent quality parameters
- Ensures consistency
- Enhances life of the product
Conforms to both European and Indian standards
Reference : India
- IS 2553 ( part 1 : 1990 )
- IS 14900 : 2000
- IS 2835 : 1987
Reference : Europe
- En 14450 : 2000
- Adheres to European toughening norms
Hardware :
Frameless Range :
- Minimalist and sleek design to make entire enclosure look aesthetically appealing
- Made of brass with nickel and chrome plating
- Automatic closing upto 300
- Tested for 5 lakh cycles
- Rust proof screws
- Screw caps
- Protective film on the hardware to prevent scratches etc
- Designed to carry loads of upto 25 kg ( per hinge )
- Gasket:
- Food grade plastic
Glass Connectors :
- Minimalist and sleek design to match the hinges
- Made of brass with nickel and chrome plating
Stabilisers :
- SS 304 grade
- Mirror finish to match chrome finish of the hinges and connectors
- 19 mm dia
Towel Bars :
- Longest towel rod ( 405 mm x 205 mm ) to hang 2 towels
- Brass with nickel and chrome finish
- 19 mm dia
- No visible screws
Plastic Parts :
Semi Framed and Frameless Range :
Made of food grade plastic
Finish
- Sleek to match with hardware
- Transparent look complementing glass
- Enhances aesthetic appeal of enclosure
Concealed magnet ensuring longer life
5 year warranty for complete peace of mind
Replacement even if it turns yellowish
Profiles instead of wall connectors
- Aluminium profiles with powder coating
- Aluminium is first cut to size , then chemically treated and then powder coated so that there is no chance of rusting
- Adjustment of 15 mm so as to cover undulations in the wall
Hinges
- Rise and fall mechanism : door rises 6 – 8 mm above the floor while opening thus preventing any chance of breakage
Sliding Range :
- Top hung channel – gives free walk way
- Wall profiles : sleek with 15 mm adjustment
- Rollers : ball bearing encapsulated in brass
- 5 year warranty on rollers
