Briza Vertical Manual : Volume 10 Ltr

Name: Briza Vertical Manual : Volume 10 Ltr
Brand: Jaquar
Rating: 5 (15 reviews)

Disclaimer:

Jaquar reserves the right at its sole discretion, to change/modify/alter any product specification at any time without notice, where improvement can be effected in design, development and dimensions.
Although the information shown in this catalogue is updated to the extent possible but the same may vary. It is advisable to consult our local representative or check in a period manner for latest technical and other updates.
The prices are subject to change without notice and those ruling at the time of supply will be charged.
Colours & sizes of product images shown in the Website may vary in reality

Rated Wattage	2000W
Volume(L)	10
Insulation/Thickness	35 mm
Outer body material	Plastic
Inner Contaner Thickness	1.8mm
Average Enamel layer thickness	0.50mm
Multi-function Safety Valve	YES
Inner Container Material (Diff. Layers)	MS
Magnesium Anode	Ø 18 mm /Length 90 mm
Inlet / Outlet Material	Stainless Steel
Heating element type	Incoloy with Glass coated heating element
Warranty	7 Years on tank, 4 Years on Element and 2 years for other components
Standing loss(Kwh/24h/45℃ diff.) (Kwh/24h/45℃ diff.)	0.332 kWh
Current BEE 5 Star threshold (Kwh/24Hr/45'C) (Kwh/24Hr/45'C)	5 Star/0.332 kWh
Thermostat Type	Capillary Sensor type
Voltage	230V~ 50Hz
Temperature Range	25-75ºC
Inlet /Outlet Pipe connection (Inch / mm)	1/2 "/12.7 mm
Shape	Square
No of elements	1
Product Dimensions (in mm)	390x330x410
