Technical Specifications
Operating Temperature -10℃ to 50℃
Operating Voltage 100-270 V
Rated Input Voltage & Frequency 220-240 V/AC & 50 Hz
Rated Input Wattage 20 W ± 10%
Rated Input Current 0.08 A
Power Factor ≥0.9
THD <10%
Rated Luminous Flux 1600 Lm
Rated Luminare Efficacy 80 Lm/W
Correlated Color Temperature (CCT) 3000K (Tolerance as per ANSI)
Color Rendering Index (CRI) >80 Ra
Beam Angle 120°
Driver Efficiency >85%
LED Life Span >50,000 Hours (Ta=25℃ @L70)
Housing Die Cast Aluminium Housing, Powder Coated
Diffuser Milky PC Diffuser
Mounting Surface
Protections
Over Voltage Protection Withstand up to 440 V/AC for 4 Hours
Surge Protection 4 KV
Protection Class Class II
Ingress Protection (IP Rating) IP54
Short Circuit Protection Provided
Open Circuit Protection Provided
Reverse Polarity Protection Provided
